THE HYDRA 21 - Faculty of Architecture and Town planning

THE HYDRA 21

HomeTechnologies3D PrintingFFF/FDM 3D PrintersTHE HYDRA 21

FDM/FFF 3D Printer - larger size

High Reliability - Low Maintenance - High Uptime - Heated Enclosure - Large Volume
  • The Hydra 21 has a 300x400mm (optionally 400x500mm) bed, heated to 120C (optionally 200C).
  • The enclosed build environment can be heated by the hotbed, and the filament storage protects your build and material from outside environmental changes
  • The Hydra 21 printers work with all Hyrel print heads, allowing you to work with numerous materials, including store-bought or home-made filaments, clays, pastes, hydrogels, photo-initiators, and cementitious materials
  • Designed with safety in mind
  • Rugged, all-metal design
  • Includes interchangeable mounting system
  • Plug-and-play modular heads
  • Ready for upgrade/expansion options
  • Compatible with large volume extruders
  • Optional 200C hotbed (larger than 300x400mm requires 208 or 220VAC)
  • Optional 3-Phase Spindle Tool
  • Optional Chilled and/or Vacuum Beds
  • Hydra 21: 250mm Z, with the following bed options:
    • Bed 43W is 400×300, 120°C
    • Bed 43H is 400×300, 200°C
    • Bed 54W is 600×400, 120°C
    • Bed 54H is 600×400, 200°C

Note, Hydra 21 models all come with a 300x300mm magnetic plate and a 300x300mm PEI-powder-coated spring-steel build surface. Printing on the larger heated bed area will require you to remove the magnetic plate and add 12mm of glass or other build surface.

TECH SPECS

BUILD VOLUME
  • X Axis 400 mm (opt. 500 mm)
  • Y Axis 300 mm (opt. 400 mm)
  • Z Axis 250 mm
POSITIONAL ACCURACY:
  • X Axis+/- 60 microns
  • Y Axis +/- 60 microns
  • Z Axis +/- 10 microns
POSITIONAL RESOLUTION:
  • X Axis 6 microns
  • Y Axis 6 microns
  • Z Axis 1 micron
CHASSIS & ENCLOSURE:
  • Powder-coated Steel & Anodized Aluminum
  • Plastic Windows
MOTION CONTROL:
  • Three Precision Ball Screws in Z-axis
  • Precision Linear Bearing System in X, Y, and Z Axes
ELECTRONICS:
  • State-of-the-art 150+ MHz 32-bit ARM processor
  • Modular, micro-stepping motor-drivers with closed-loop encoding
  • Integrated, Dual CAN-bus architecture
  • “Smooth Move” motion control technology firmware
TABLET PC:
  • USB: Four USB 2.0 Ports (External)
  • WLAN: WiFi Capable
